TOA IR-700D Infrared Wireless Distributor
Product Overview
The IR-700D is a receiver distributor used in the TOA's infrared wireless microphone system.It employs 4 receiver mixing inputs and 2 distribution outputs. By using the IR-700D in conjunction with the IR-702T Infrared Wireless Tuner, up to 16 infrared wireless receivers can be connected to the IR-702T.
Features
- Equipped with 4 receiver mixing inputs and 2 distributor outputs
- By using the IR-700D in conjunction with IR-702T and YW-1022/YW-1024, a system with up to 16 infrared receivers is configurable
Specifications
- Power Source
- AC mains, 50/60 Hz (use of the supplied AC adapter)
- Power Consumption
- 25 W or less
- Infrared Receiver Input
- 75 Ω, BNC jack x 4 (Infrared wireless receiver's power source: 24 V DC, 800 mA max. in total of 4 terminals)
- Number of Connectable Infrared Receiver
- 16 (YW-1024 x 4)
- Input/Output
- 4 mixing inputs, 2 distribution outputs
- Band-Pass Frequency
- 3.0 - 6.0 MHz
- Gain
- 0 dB (±3 dB)
- Distribution Output
- 75 Ω, BNC jack
- Operating Temperature
- -10 ℃ to +50 ℃ (14 ℉ to 122 ℉)
- Operating Humidity
- 30 % to 85 %RH (no condensation)
- Finish
- Case: ABS resin, black
- Dimensions
- 210 (W) x 44 (H) x 200.9 (D) mm (8.27" x 1.73" x 7.91")
- Weight
- 640 g (1.41 lb) (unit only)
- Included Accessories
- AC adapter* (DC cord length: 1.8 m (5.91 ft) x 1, AC Power cord (2 m (6.56 ft) …1, BNC plug-to-BNC plug cord (50 cm (1.64 ft) …1, Rubber foot …4
- Optional Accessories
- Rack mounting bracket: MB-WT3, MB-WT4 (for mounting with the optional IR-702T together)
